Pair of 1372mm Heavy Duty Bolt on Fork Extensions
Pair of 1372mm Heavy Duty Bolt on Fork Extensions
Pair of 1372mm Heavy Duty Bolt on Fork Extensions

Pair of 1372mm Heavy Duty Bolt on Fork Extensions

From £316.40 +VAT

Fork extensions offer a straightforward yet reliable way to manage those rare, lengthy loads that protrude beyond the tips of the parent fork arms (up to a 66% overhang). Widely used in construction and lifting operations, these extensions feature a smooth underside that helps prevent damage to the load.

Enquire
Product Specifications
Clear
SKU: N/A

Description

About the 1372mm Fork Extensions

Fork extensions offer a straightforward yet effective way to handle long or awkward loads that extend beyond the tips of the main fork arms (up to a 66% overhang). They’re widely used in construction and lifting operations, where their smooth underside helps protect the load from damage.

  • Tip thickness 6mm for ease of splitting packs
  • Single channel fabrication with fully plated underside
  • Fully pressed profile with rounded corners
  • Zinc plated heel pins for safe attachment to truck
  • Fully enclosed finish on all 4 sides
  • Painted black
Model Ref To Suit Fork Width (mm) Extension Length (mm) Max Fork Section (mm)
IFE454 100 1372 100 x 50
IFE554 125 1372 125 x 50
IFE654 150 1372 150 x 50

OPERATION

  • Position forks to desired distance apart.
  • Remove fork pocket heel pins from the extensions.
  • Drive forks into the fork extensions.
  • Insert the fork pocket heel pins directly behind the heel of the fork and attach safety lynch pin into the holes provided.
  • The extensions are now ready for use.
